Desulfurization Gypsum Briquette Machine
1-30 million tons of production
desulfurization gypsum, coal, steel slag, fluorite
Desulfurization gypsum and natural gypsum composition is similar, can be used as cement retarder, and at present the government promote energy conservation and emission reduction, waste residue utilization, conservation of resources, environmental protect
We're here to help: Easy ways to get the answers you need.
Desulfurization gypsum and natural gypsum composition is similar, can be used as cement retarder, and at present the government promote energy conservation and emission reduction, waste residue utilization, conservation of resources, environmental protection and other policies. Now the cement plants use desulphurization gypsum instead of natural gypsum as the cement retarder.
Zhongzhou desulfurization gypsum briquette machine will directly press desulfurization gypsum powder into 20-80mm round briquettes and without any adhesive, and the production rate above 95%, the hardness of briquettes pressed is very strong, should not be easily broken when handing and loading, and then supplied to the cement plant using retarder instead of natural gypsum, desulfurization gypsum briquettes product purity guaranteed, direct forming and into briquettes, high strength, suitable for all kinds of transportation, improve product transportation capacity; desulfurization gypsum briquette machine has the advantages of compact structure, convenient maintenance, simple operation, short process, low energy consumption, low failure rate, the main part rollers adpot materials 9Cr2 steel forging, greatly improved the wear resistance and pressure resistance, so the whole machine has a long service life.
Zhongzhou desulfurization gypsum briquette machine according to the customer's demands to provide the following process:
Project 1. desulfurization gypsum--- hopper silo--- press machine---briquette machine---final briquettes product
Project 2. desulfurization gypsum--- hopper silo--- rotary dryer----press machine---briquette machine---final briquettes product
Project 3. desulfurization gypsum--- hopper silo--- rotary dryer----press machine---briquette machine---vertical dryer---final briquettes product
Project 4. desulfurization gypsum--- hopper silo--- rotary dryer----press machine---briquette machine---turning dryer---final briquettes product
Desulfurization gypsum briquettes production supporting equipment are as follows:
1. Gypsum powder: a waste produced in the desulfurization system, can be used as cement retarder
2. Special gypsum feeder: control of the whole production line, solve with gypsum wall not falling, not continuous and uniform feeding, ensure special equipment for drying machine feeding uniform.
3. Rotary dryer: the water is higher than 12% of the desulfurization gypsum be dried to below 8%-10%, easy to pressing briquettes.
4. Press machine: press desulfurization gypsum more solid, increase the density of gypsum, a kind of auxiliary equipment. Press machine improve the briquetting rate of desulfurization gypsum, the characteristics is as following: It works for loose materials that not easy to be formed , Pre exhaust and compaction, make materials be briquetted easily, the machine assembling reasonable ,compact structure, stable operation, reliable performance.
5. Desulfurization gypsum briquette machine: press gypsum into briquettes withour any binder, the production rate more than 95%.The final briquettes is more hard, can be keep the shape when loading and unloading in transportion. Product purity guaranteed.
6. Turning dryer: it is to drying gypsum briquettes below 3% water content. The gypsum briquettes is evenly placed in the net, through the hot air drying to complete drying task.
7. Vertical dryer: It also can be used for drying final briquettes, the gypsum briquettes was put into the top of dryer by belt conveyor, and in the process slow down, the hot air bring the water of briquettes, quickly be dried to 3% moisture, this machine has small area, easy operation and low maintenance cost.
Zhongzhou company based on desulfurization gypsum briquette press equipment technical services, to create maximum value for clients, The desulfurization gypsum briquette machine produced has the high pressure, high finished product rate, high strength, fully meet the requirements of the operation of lime production, cost reduction for lime production, optimized operation, create the conditions for the realization of maximum benefit, we sincerely welcome all enterprises to explore, mutual benefit and win-win.
|Power||7.5 kW||11 kW||18.5kW||22kW||37kW||55kW||90 kW||110kW|
|wear-resistant alloy||wear-resistant alloy||wear-resistant alloy||wear-resistant alloy|
|Roller assemble||Split-clamp type||Temper assembly||Temper assembly|
|Hardness of roller||52-62 HRC||52-62 HRC||52-62 HRC||52-62 HRC||52-62 HRC||52-62 HRC||52-62 HRC||52-62 HRC|
|Pressure structure||Four-rollers double pressure||Four-rollers double pressure||Four-rollers double pressure|
Four rollers double pressure
after the first pressurization, the materials between main and auxiliary rollers enter the place between two main rollers for a second pressurization, where the pressure will be twice of the type of two rollers.(the auxiliary roller pre-press the hemisphere on the amin roller to exhaust air, the hemisphere will be pressed again into briquettes fomation through two main rollers).
GB standard hydraulic components
manufaturing by Dezhou oil pump company, using embolism type pump equipped with storage device which can be operation of protection briquette machine when the hydraulic moment fluctuation, the oil cylinder adopts compound type and be made of standard material 27SiMn, extremely good finish, wear resistance, having protective effect on seals.
Roller taper assembly techology(patent)
Roller and wheel hub of briquette machine is processed into tamper structure, which shall be compacted firmly by bolts for stability and reliance, easy to replace roller,save time and efforts for users.
9Cr2 forging rollers
the roller materials adpot 9Cr2 forging steel, high precision and abrasion resisitant, the rigidity reach to 55-60HR through prempering.
National standard bearing
Using the rolling mill bearing series, each model is the double row cylindrical ball bearing, well-known brands, lagre load bearing, stable performance, guarantee period of 5 years.
Split plummer block
Unique split type design, precision machining, simply remove the bolts when the user maintenance, open housing, can be seen bearing, ease of maintenance.
Independent production, full steel material bell housing, gears made of 40Cr steel, stable performance.
high quality finished No.45 steel tempering.
