Charcoal Briquette Machine
1-30 million tons of production
metallurgy, refractories, power plant, chemical industry, energy, transportation, heating, industry, agriculture, animal husbandry, barbecue and other fields
Zhongzhou charcoal briquette machine can also be used to press biomass carbon powder, charcoal powder, bamboo carbon powder and coke powder, graphite powder, carbon powder, page shell carbon, activated carbon, coconut shell charcoal etc powder materials
We're here to help: Easy ways to get the answers you need.
Zhongzhou charcoal briquette machine can also be used to press biomass carbon powder, charcoal powder, bamboo carbon powder and coke powder, graphite powder, carbon powder, page shell carbon, activated carbon, coconut shell charcoal etc powder materials, can be processed into square, oblate, elliptical, oval, bread, pillow and other special shapes. Carbon powder briquettes are widely used in metallurgy, refractories, power plant, chemical industry, energy, transportation, heating, industry, agriculture, animal husbandry, barbecue and other fields.
Based on many years of sales experience, the majority of customers use briquette machine to produce charcoal briquettes to barbecuing or heating. Here we want to remind users, our charcoal briquette machine can not be directly pressed peanut shell, coconut shell, rice husk, sawdust etc biomass materials, it must first be carbonized raw materials into charcoals , then crush it into charcoal powder, briquetting in the end.
According to different situation of raw materials, customer can refer to the following:
raw materials---crusher---rotary dryer---carbonizer---mixing machine---briquette machine---dryer
If your raw materials were carbonized, you can think about this two method:
A: raw materials---crushing machine---mixing machine----briquette machine---dryer
B: raw materials---mixing machine---briquette machine----dryer
Before briquetting, the raw materials must be in 0-5mm, its moisture should be controlled in 8-10% with binder.
If you have any question on charcoal briquettes production, please feel free to call our hotline at any time, or send email to us, we will be sincere to help your project. ZHONGZHOU charcoal briquette machine is specifically designed for briquetting charcoal etc biomass materials, it has high productivity, high degree of automation, production efficiency,low failure rate, easy maintenance, so Zhongzhou charcoal briquette machine was welcomed by many enterprises at home and abroad.
|Power||7.5 kW||11 kW||18.5kW||22kW||37kW||55kW||90 kW||110kW|
|wear-resistant alloy||wear-resistant alloy||wear-resistant alloy||wear-resistant alloy|
|Roller assemble||Split-clamp type||Temper assembly||Temper assembly|
|Hardness of roller||52-62 HRC||52-62 HRC||52-62 HRC||52-62 HRC||52-62 HRC||52-62 HRC||52-62 HRC||52-62 HRC|
|Pressure structure||Four-rollers double pressure||Four-rollers double pressure||Four-rollers double pressure|
Four rollers double pressure
after the first pressurization, the materials between main and auxiliary rollers enter the place between two main rollers for a second pressurization, where the pressure will be twice of the type of two rollers.(the auxiliary roller pre-press the hemisphere on the amin roller to exhaust air, the hemisphere will be pressed again into briquettes fomation through two main rollers).
GB standard hydraulic components
manufaturing by Dezhou oil pump company, using embolism type pump equipped with storage device which can be operation of protection briquette machine when the hydraulic moment fluctuation, the oil cylinder adopts compound type and be made of standard material 27SiMn, extremely good finish, wear resistance, having protective effect on seals.
Roller taper assembly techology(patent)
Roller and wheel hub of briquette machine is processed into tamper structure, which shall be compacted firmly by bolts for stability and reliance, easy to replace roller,save time and efforts for users.
9Cr2 forging rollers
the roller materials adpot 9Cr2 forging steel, high precision and abrasion resisitant, the rigidity reach to 55-60HR through prempering.
National standard bearing
Using the rolling mill bearing series, each model is the double row cylindrical ball bearing, well-known brands, lagre load bearing, stable performance, guarantee period of 5 years.
Split plummer block
Unique split type design, precision machining, simply remove the bolts when the user maintenance, open housing, can be seen bearing, ease of maintenance.
Independent production, full steel material bell housing, gears made of 40Cr steel, stable performance.
high quality finished No.45 steel tempering.
15 ton Coal Briquettes Production Plant in Congo
In March, 2016, our coal briquettes production plant was exported to Congo. This briquette plant includes coal briquette machine, crusher, double shaft mixer and binder mixer.
One set rotary dryer shipped to Vietnam
Rotary dryer is mainly applied to drying river sand, dry-mixed mortar, yellow sand, cement clinker, clay, coal gangue, mixtures, coal ash, gypsum, iron powder and other raw materials, widely used in building materials, chemical industry, casting industry and other industries.
One set coal briquette machine shiped to Lagos
Coal briquette machine can press coal powder, coke powder, coal gangue, and fly ash into ball shape. It not only reduces energy consumption, but also promotes the sustainable development strategy.
The production field in Indonesia north
Coal is the applicable and energy,so if waste the coal,it will be wasteful.So some people think that we can press coal into briquettes to storage for storage,thus coal is made full use and save energy,improve efficiency.Atthe same time,we need one machine to press coal into balls.Henan Kefan is the professional coal briquette machine supplier in China,we can supply other briquette makers,such as charcoal powder briquetting machine,etc.We can supply best products and best service,and customers who have brought our products all over the world give our products high praise.
